JA Solar 605W| DeepBlue 4.0 Pro| Bifacial Monocrystalline Module

Description

General Data

• Cell Technology: Monocrystalline PERC, 144 half-cells
• Dimensions: 2384 × 1134 × 35 mm
• Weight: 34.2 kg
• Glass Type: 2.5 mm tempered glass (front and back)
• Frame: Reinforced anodized aluminum alloy
• Junction Box: IP68, 3 bypass diodes
• Connector: MC4-compatible
• Cable Length: Portrait: 300 mm (+) / 400 mm (−); Landscape: 1400 mm (+/−)

Electrical Parameters at STC

• Rated Power (Pmax): 605 W
• Voltage at Max Power (Vmp): 45.53 V
• Current at Max Power (Imp): 13.29 A
• Open Circuit Voltage (Voc): 53.61 V
• Short Circuit Current (Isc): 14.08 A
• Module Efficiency: Up to 22.1%
• Power Tolerance: 0 to +5%
• Bifaciality Factor: 80 ± 5%

Operating Conditions

• Max System Voltage: 1500 V DC
• Operating Temperature: –40°C to +85°C
• Mechanical Load: 6000 Pa (snow) / 3000 Pa (wind)
• Warranty: 12-year product, 30-year linear power output (87.4% output guarantee)
